ZTIC Disc High Speed Spinning Centrifuge Separator Multifunctional

Brand Name : ZTIC

Certification : ISO, CE

Place of Origin : Henan, China

MOQ : >=1 Sets

Price : $10,000.00

Supply Ability : 100 Set/Sets per Month

Packaging Details : Standard packing or according to customer's requirement

Condition : New

Type : Centrifuge

Voltage : Depands

Warranty : 1 YEAR

After-sales Service Provided : Field installation, commissioning and training, Online support

Key Selling Points : Long Service Life

Applicable Industries : Manufacturing Plant, Construction works , Energy & Mining

After Warranty Service : Video technical support, Online support

Local Service Location : Viet Nam, Indonesia, Australia, Argentina

Showroom Location : None

Product external water : 5-8%

Capacity : ~2000L/h

Port : QingDao,ShangHai,TianJin

Dimension(l*w*h) : 918mmx545mmx924mm

Power(w) : 4kw

Weight : ~310 kg

Contact Now

ZTIC Multifunctional Disc High Speed Spinning Centrifuge Separator

Minute Leave machine install Complete Hold do regulation but

The separator is a high-speed rotating machine, and the drum generates huge centrifugal force when it is working. In order to ensure the safety of operators and equipment , the following rules should be strictly followed during use:

  • Before the main lock cap of the drum is locked and the inlet and outlet devices and other fastening screws are not fastened, the separator cannot be started. Do not loosen any part of the machine until the drum has come to a complete stop.
  • Flame heating or repair welding of all parts of the drum is not allowed.
  • If there is abnormal vibration and abnormal sound when the separator is working, it should immediately cut off the power supply and stop it immediately.
  • Parts of the drum cannot be exchanged with other drum parts, even the same type of separator is not allowed.
  • When the "O" assembly mark of the main lock cap crosses the corresponding mark of the drum body by more than 25°, Users should stop using it immediately and contact our company in time.
  • The separator must not be used to process materials that are more corrosive than the factory design.
  • In the process of use, if the wear of the drum body exceeds 1mm, the user should stop using it immediately and contact our company in time.
  • If the main parts of the separator are found to have quality problems, we must notify our company in time, and users are not allowed to replace and repair without authorization, so as not to damage the machine and affect safe production. Please use the spare parts provided by our company.
  • When the separator has been used for two years or its vibration intensity exceeds 4.5mm/s and cannot be reduced, non-destructive testing of the drum parts and shafts must be carried out and the dynamic balance of the drum part must be checked. Flaw detection will be required every year thereafter.

If the user violates the above operating rules, all the consequences arising therefrom shall be the responsibility of the user.

The main technical parameters of a separator

  • Model KYDR204
  • The inner diameter of the drum 250mm
  • The speed of the drum about 8350r/min
  • Counter speed 120r/min
  • Separation factor 9760
  • Rated capacity ~2000L/h
  • Motor model Y112M-4 B5
  • Power 4 kw
  • Dimensions (LxWxH) 918mmx545mmx924mm
  • Mass ~310 kg

working principle

Using the principle of obtaining different sedimentation velocities in the centrifugal force field by using the light, heavy or solid phases with different densities and immiscible in the mixed liquid (mixed corrosion liquid), the separation and stratification or the sedimentation of solid particles in the liquid are achieved. Purpose.

The separated material is fed into the heart of the machine, that is, the inside of the drum. Under the action of a strong centrifugal force, the material (mixed liquid) passes through the separation interval of a set of disc bundles. The neutral hole of the disc is used as the interface, and the specific gravity The larger liquid (heavy phase) moves along the disc wall to the outside of the neutral hole, where the heavy slag accumulates in the sediment area, and the liquid (light phase) with a smaller specific gravity moves upward along the disc wall and converges to the small centripetal pump , output from the small centripetal pump.

ZTIC Disc High Speed Spinning Centrifuge Separator MultifunctionalZTIC Disc High Speed Spinning Centrifuge Separator MultifunctionalZTIC Disc High Speed Spinning Centrifuge Separator MultifunctionalZTIC Disc High Speed Spinning Centrifuge Separator Multifunctional
